Commercial & Industrial

Test Stands AND custom PRODUCTS for Industrial & commercial applications

Chant Engineering has had a long history of designing and manufacturing custom test stands and other custom products for commercial and industrial applications.

Contact us for a quote

held to higher standards


Over 54 Years of Testing Machinery You Can Trust

Chant Engineering is known as a leader in manufacturing of heavy-duty testing equipment for industrial and commercial applications.

Chant Engineering’s typical test stand capabilities include:


Pressure
Flow
RPM
Temperature
Dynamic

Static
Fatigue
Position
Force
Torque
ISO 9001/ AS9100D & PJLA 17025 Seal

Chant is accredited and certified to the following industry standards:

  • ISO 9001:2015
  • AS9100D
  • ISO/IEC 17025:2017 Accredited

TEST STANDS FOR INDUSTRIAL APPLICATIONS

Power Steering Pump Test Stand

Model 10358-01

Chant Model 10358-01 Power Steering Pump Test Stand is designed to test a single power steering pump at any given time with the capacity to accommodate different pump styles by the means of interchangeable fixture plate arrangement.

Features a touch screen operator controls that displays, RPM, Oil Temperature (OF), and Flow (GPM), Pressure (PSI), Torque (IN-LBS) and other parameters.

Germicidal UV Light Mobile Disinfection System

Chant Engineering’s Germicidal UV Light Mobile Disinfection System will disinfect and deactivate SARS-CoV-2 on large-sized items like pallets, large tools, and equipment. This unit will disinfect in less than one minute and can be modified with conveyor systems for use in shipping, aircraft, and manufacturing facilities.

For more information, view the UV Disinfection System datasheet here.

40k cLAMPING/ 10,000 PSI STATIC PRESSURE VERTICAL TEST STAND

Model 10311-01

Chant Model 10311-01 40K Clamping / 10,000 Psi Static Pressure Vertical Test Stand is used to test high-pressure valves and other products. This semi-automatic test stand includes a 48″ wide operator control console, touch screen display and monitor, and two ballistic enclosed test areas. One enclosure is for water/glycol testing and the other is for hydraulic testing.



pneumatic Test Stand

Model 93400601

Chant Model 93400601 Pneumatic Test Stand is used to test pneumatic components used in military aerospace applications.

    30,000 psi hydrostatic Test STand

    Model 10891-01

    Chant Model 10891-01 Hydrostatic Test Stand is used to test high-pressure valves and other products. This semi-automatic test stand includes a 48″ wide operator control console, touch screen display and monitor, and two ballistic enclosed test areas. One enclosure is for water/glycol testing and the other is for hydraulic testing.



    300K CLAMPING/ 10,000 PSI STATIC PRESSURE hydrostatic TEST STAND

    Model 10730

    Chant’s Model 10730-01 300K Hydrostatic Test Station Horizontal Stand is hydraulically operated. It consists of a Hydraulic Power Unit (HPU), a Hydrostatic Test Station and a Hydrostatic Water Console.

    The HPU includes the operator control panel, hydraulic motor and pump, and input power wiring. Load testing will be performed from the hydraulic power unit’s control console and the Hydrostatic Water Console.



    300K CLAMPING/ 10,000 PSI STATIC PRESSURE hydrostatic TEST STAND

    Model 10730

    Chant’s Model 10730-01 300K Hydrostatic Test Station Horizontal Stand is hydraulically operated. It consists of a Hydraulic Power Unit (HPU), a Hydrostatic Test Station and a Hydrostatic Water Console.

    The HPU includes the operator control panel, hydraulic motor and pump, and input power wiring. Load testing will be performed from the hydraulic power unit’s control console and the Hydrostatic Water Console.



    Hurricane Wind Simulator

    Model 9743-CWT

    Chant Model 9743-CWT Cyclic Wind Test Fixture is used to simulate cyclic wind load on windows, doors and other building products. It uses a vacuum on the test specimen to simulate a wind load. The test specimen can be any type of building product used in any type of construction. Typically the hurricane tests are done on windows and doors, but any item can be tested.

    The vacuum on a specimen is increased to a set value then vented to atmosphere to simulate one wind load cycle. The charging of a vacuum and venting to atmosphere is repeated numerous times for repetitive loading. The Chant Cyclic Wind Test Fixture has the capability to run cycles non-stop.

    This unit consists of a mounting fixture, support frame, vacuum pump skid, pressure gauges, a pressure transducer, control valves, and a computer controlled operator HMI and data acquisition system.

    Small missile impactor

    Model 8915-SMI

    Chant Model No. 8915-SMI Small Missile Impactor uses compressed air as a propellant to launch (10 ea.) 2 gram steel balls at speeds up to 132 ft/s to test building products. Our Small Missile Impactor consists of a 1-inch diameter x 4 ft long barrel, support frame, an integral air storage chamber, an air pressure regulator, pressure gauges, an electric trigger valve, velocity sensors, and a velocity meter.

    The air storage chamber is welded to the barrel to minimize air restriction. A steel frame supports the barrel and air chamber at a convenient height for the operator. An adjustment at the front of the gun allows for adjustment of the barrel pitch. Sensors for measuring missile velocity are mounted at the end of the barrel on a 2-inch spacing. The sensors are connected to the digital meter to display the missile velocity. The operator can adjust missile velocity by varying the air pressure with the regulator valve. By increasing the air pressure in the chamber the operator can obtain a higher missile velocity. A pressure gauge on the breech displays the chamber pressure.

    The operator controls the firing of the Impactor from the integral control console. The console consists of a charge button, a protected firing switch, and a velocity meter.

    large missile impactor

    Model 8915-LMI

    Chant Model No. 8915-LMI Large Missile Impactor uses compressed air as a propellant to launch (1) 8 ½ ft long 2″ X 4″ lumber at speeds up to 52 ft/s at a 10″ diameter target. Our Large Missile Impactor consists of a 4-inch diameter x 12 ft long barrel, support frame, an integral air storage chamber, an air pressure regulator, pressure gauges, an electric trigger valve, velocity sensors, and velocity meter.

    The barrel is constructed from smooth bore steel tubing. The air storage chamber is welded to the barrel to minimize air restriction. A steel frame supports the barrel and air chamber at a convenient height for the operator. Sensors for measuring missile velocity are mounted along the barrel length at a 2-ft spacing. The sensors are connected to a digital meter to display the missile velocity. The operator can adjust missile velocity by varying the air pressure with the regulator valve. By increasing the air pressure in the chamber the operator can obtain a higher missile velocity. The chamber pressure is displayed on a pressure gauge. The launching pressure of the barrel is calculated to be approximately 5 psi using a 10 lb. missile with an exit velocity of 52 ft/sec.

    The operator controls the firing of the Impactor from a single control console. The console consists of a chamber pressure regulator, pressure gauge, a protected firing switch, and a velocity meter.



    11293 Hydraulic Test Stands

    Hydraulic Test STands

    Model 11293

    Chant Engineering Model 11293 consists of 3 separate units that include a stainless steel cabinet/frame assembly to hold the necessary valves, pumps, and other components required for the test system.  Stainless steel is used both for appearance and durability.

    The cabinet provides a test station for mounting the pumps that will be tested.  A drip pan with collection tank below will collect any spilled fluid.  The footprint of the test stand will be no greater than 4ft x 7ft.

    Tri-Axial Servo Hydraulic Testing Machine

    Model 828901

    The Chant Model 828901 is a large servo-hydraulic testing machine. This is one of the worlds largest machines used to structurally test 8 ft. x 24 ft. sections of ships hulls. The physical size of the machine is approximately 40 ft. long x 25 ft. wide x 15 ft. tall.

    In use, this machine uses a Chant Engineering designed real-time computer controlled servo-hydraulic system to simultaneously push and pull steel hull sections with up to 5 millions lbs. of force longitudinally, 1.2 million lbs. of force laterally and 700,000 lbs. from below. All individual actuator forces and displacements are controlled by and displayed on the computer. The specimens are strain gauged by the user and the results displayed on a separate computer. All controls are in a soundproof operator control room.

    CTS Series compression test system

    Model 50

    The Chant Model 50 CTS Series Compression Test System can be ordered in a variety of standard capacities and sizes. It can also be customized to your specifications. Our CTS Series of machines are designed to efficiently and accurately test the performance of individual packages, containers, pallets and unit loads under compressive forces.

    The CTS is capable of performing the latest industry standard package testing specifications. A closed loop control with state of the art technology is used to guarantee accuracy, tight control and repeatability. The CTS is capable of running a test up to maximum capacity for up to and including 24 hours.

    .

    Compression Test Machine

    Model 9142

    The Chant Engineering Model 9142 Compression Test Machine is an example of a standard off the shelf 11,000 capacity compression test machine with a 4-post design and platen size of 48″ x 48″, capable of swivel or fixed.

    The machine is operated by two ball screws with a clear space 52″ x 52″. Other features include; Electronic Load cell, computer & printer software for control, data acquisition, graphs, reports, manual controls on the machine for set up, and display on machine with load/distance.

    Mechanical limit switches up and down for safety. Settable limits of displacement during a load test. Settable limits of force during velocity mode. Live real-time graph on the computer showing load and displacement.

    100K Torque Testing MAchine

    Model 9100

    Chant Model No. 9100-100K Torque Testing Machine is used to perform static torque tests from 10,000 in-lbs to 100,000 in-lbs on test shafts up to 20 feet long. The 9100-100K Torque Testing Machine comprises a 25 ft long torque loading frame, an adjustable reaction head, a torque-loading spindle, a portable hydraulic power source with control valves, torque cell, and a control panel with digital display.

    At one end of the loading frame is the torque-loading spindle. The torque is applied to the spindle from a hydraulic actuator attached to a lever arm. Varying the pressure to the hydraulic actuator controls torque. The actuator can apply a static torque through a 20 deg arc. For reading torque, a 100,000 in-lb torque cell with .1% accuracy is attached to the end of the loading spindle. The test shaft attaches to the loading spindle using the customer’s specified bolt circle. At the opposite end the loading frame is an adjustable reaction head. The reaction head clamps to the top surface of the loading frame and is infinitely adjustable.



    Top Lift test system

    Model 9121

    Chant Model 9121 Top Lift Test System is for testing Intermediate Bulk Containers (IBCs) in accordance with the requirements of U.S. Department of Transportation’s Title 49 CFR, Section 178.812 as well as other testing standards.

    The Model 9121 Top Lift Test System is designed to test flexible or ridge containers that are designed to be lifted from the top by means of integral attached lifting points, eyes, loops, straps, etc. The Model 9121 has a maximum downward force capacity of 50,000 lbs. and comes complete with the hydraulic power unit (HPU)/operators control station shown.

    The operator manually controls the test and the load from the electronic load cell which is displayed on the digital indicator. The unit comes standard with 25 ft. of interconnected hoses/cables, and both the test frame and the HPU/operators control station are on wheels for ease of use. The Model 9121 has fully adjustable attachment points for any size container. Pressing platens of any size can be provided as required.
